Parts List
No. Description QTY No. Description QTY
1 Main frame 1 34 Flat washer d10X1.5 6
2 Handlebar post 1 35 Nylon nut M10 6
3 Front stabilizer 1 36 Nut cap S16 4
4 Rear stabilizer 1 37 Hex bolt M10X50 2
5 L/R Pedal support (L/R) 1 pr. 38 L/R Pedal locking bolt (L/R) 1 pr.
6 L/R Swing bar(L/R) 1 pr. 39 Axle bushing Φ24 X20XΦ16.1 4
7 L/R Handlebar (L/R) 1 pr. 40 L/R Connecting joint (L/R) 1 pr.
8 Armrest 1 41 Spring washer Φ13 XB2 2
9 Computer 1 42 L/R Nylon nut (L/R) 1 pr.
10 L/R Pedal (L/R) 1 pr. 43 Nut cap S19 2
11 Front end cap 2 44 Arc washer Φ20 Xd8X2XR16 4
12 Carriage bolt M10X57 4 45 Carriage bolt M8X40 4
13 Arc washer Φ10X1.5XΦ25XR28 4 46 Mushroom end cap 2
14 Acorn nut M10 4 47 Handlebar foam grip 2
15 Rear end cap 2 48 Armrest foam grip 2
16 Allen screw M8X16 4 49 Round end cap Φ25X1.5 2
17 Tension controller 1 50 Pulse sensor wire 2
18 Extension wire 1 51 Hex bolt M8X30 2
19 Tension cable 1 52 Spring washer D8 4
20 Sensor wire 1 53 Handlebar chuck cover 1
21 Cross screw M5X45 1 54 Waveform washer Φ20XΦ28 X0.3 2
22 Crank 1 55 Cross screw M4X12 2
23 Nut cap S14 4 56 Arc washer Φ20Xd8.5XR25 4
24 Hex bolt M8X15 2 57 Nut cap S13 2
25 Flat washer Φ8.2XΦ32 X2 2 58 Acorn nut M8 4
26 Axle bushing Φ32 X2.5 6 59 Flat washer D5 1
27 Handlebar shaft 1 60 Tension controller cover 1
28 Round end cap Φ28 X1.5 2 61 Alloy bushing Φ14X10XΦ10.1 4
29 Square end cap 40X25X1.5 4 62 Waveform washer D17X0.3 2
30 Hex bolt M8X55 2 63 Hex bolt M6X45 2
31 Flat washer d8 X1.5 2 64 Nylon nut M6 2
32 Nylon nut M8 2 65 Roller 2
33 Hex bolt M10X45 4
NOTE:
Most of the listed assembly hardware has been packaged separately, but some hardware items have
beenpreinstalledintheidentiedassemblyparts.Intheseinstances,simplyremoveandreinstall
the hardware as assembly is required. Please reffer to the individual assembly steps and note of all
preinstalled hardware.
