4 Introduction
5WPMAN0148 (Rev. 2/16/2009)
SPECIFICATIONS
RB1172 RB1184 RB1196
Overall Height 40" (102 cm) 40" (102 cm) 40" (102 cm)
Moldboard Height 18" (46 cm) 18" (46 cm) 18" (46 cm)
Working Width 72" (183 cm) 84" (213 cm) 96" (244 cm)
Moldboard Thickness 5/16" (7.9 mm) 5/16" (7.9 mm) 5/16" (7.9 mm)
Overall Depth 50" (127 cm) 50" (127 cm) 50" (127 cm)
Weight 530 lbs. (240 kg) 565 lbs. (256 kg) 600 lbs. (272 kg)
Cutting Edge 1/2" x 6" 1/2" x 6" 1/2" x 6"
(1.3 x 15 cm) (1.3 x 15 cm) (1.3 x 15 cm)
Reversible Reversible Reversible
Offset Position Left or Right 4", 10", 16" 4", 10", 16" 4", 10", 16"
(10, 25, 41 cm) (10, 25, 41 cm) (10, 25, 41 cm)
No. of Forward Positions 9 9 9
No. of Backfill Positions 9 9 9
No. of Tilt Positions 5 5 5
Tractor 3-Point Cat 1 or 2 Cat 1 or 2 Cat 1 or 2
Quick Hitch (Optional) Cat 1 or 2 Cat 1 or 2 Cat 1 or 2
Implement Code
for Tractor Ballast 36.4 38.8 41.2
Tractor HP Rating 75 HP max 75 HP max 75 HP max
(56 kW) (56 kW) (56 kW)
NOTES
