- 11 -
EN
Model: UMC-GA1F2T
ON
1
2
3
4
DIP
NO
Function
Status
Description
1
2
Reserved
Jumbo
Frame
X
X
Up to 9KB
FX 100M
FX 1000M
Normal (Up to
1500Bytes)
ON
OFF
3
4
FX Speed Set
Disable
Enable
ON
OFF
OFF
ON
NOTE:
If enabled, Layer 2 network trac will not be
forwarded between the two RJ45 ports in the same VLAN.
Port Isolation
1
1
11
13
Table of Contents
Hardware Overview
5
Front Panel Ports
5
Status Description
7
Rear Panel
10
Bottom Panel (DIP Switch)
11
Site Environment
14
Desk Mounting
15
Connecting to the Power
17
Troubleshooting
22
Online Resources
23
Product Warranty
23
Installation
37
Montage auf einem Tisch
37
Anschluss an das Stromnetz
39
Fehlerbehebung
44
Aperçu du Matériel
49
Indicateurs LED
51
Panneau Arrière
54
Montage Sur Support
59
Dépannage
66
Garantie du Produit
67
Compliance Information
