66
1. OVERVIEW
This section of the down tube and the battery shows how the battery
must rest rmly (yellow) on the inner wall of the tube, while on the other
sides, a minimum distance must be respected which can vary according
to the construction tolerances of the frame, we recommend at least 1mm
minimum space. The controller must be screwed in perfectly.
2. BATTERY AND CONTROLLER
Dimensions: Length 469mm. Section 42.0 x 49.5mm.
