FSK HAWK PANIC PACK - Wiring Connections; AC Power and Transmitter Connections; Output and Battery Connections

HAWK PANIC PACK
3
12V
DC ON
SIREN
RADIO
GND
1
AC 17V
ARMED
12V OUT
+
-
12V OUT
+
-
BATT
+
-
CAC
7
RADIO
C
AC
12V OUT
200 mA
MAXIMUM
}
AC FAIL SENSE
TO TRANSMITTER
NOT USED
FOR SIREN ONLY
TO TX75X INPUT 7
+
_
12V DC
POWER
TO
TRANSMITTER
}
+
_
}
+
_
}
AC FROM
TRANSFORMER
+
_
BATTERY
12V
7AH
}
SIREN 12V
(IF USED)
MAX 25W
+
_
}
12V OUT
200 mA
MAXIMUM
14V AC
NOT USED
FOR SIREN ONLY
TO HAWK INPUT 7
