2 Please read before powering up your ODS
Please see Panel Diagrams in next section 3 for assistance.
1) Inspect to make sure power & pre-amp tubes are intact & snuggly seated in
their sockets.
2) Make certain a speaker (load) is plugged into the correct speaker input jack
on the back of the amplifier (4 or 8 ohm). Failure to have a speaker
connected to the amp will result in damage to the output tubes! Your ODS is
supplied with multiple speaker inputs for various impedances, select the one
closest to your speaker(s) impedance.
3) Reduce Front PANEL controls (MASTER, GAIN, INPUT, OUTPUT) to moderate
levels (approx at 7-9 o’clock positions).
4) Install cable into footswitch (either standard or Artist) and then connect into
rear panel input marked FOOTSWITCH. (Standard uses ¼” phone jack,
Artist/Artist Plus uses 5-pin MIDI jack.
5) Install instrument cable from guitar into front panel INPUT
6) Be sure both POWER and STANDBY switches (rear panel) are in DOWN
position.
7) Install power cord to ODS amplifier (AC POWER IN) and to AC power source.
8) POWER UP amplifier by: 1) flipping POWER switch UP. WAIT at least 1 minute
for tubes to heat up. 2) Flip STANDBY switch UP, amplifier will now operate.
9) The Amplifier is now fully on and ready to use. Feel free to adjust all controls
as you see fit.
TO PUT AMP IN STANDBY MODE- Simply flip the STANDBY switch DOWN.
TO PUT AMP IN PLAY MODE
- Simply flip the STANDBY switch UP.
TO TURN AMP OFF Flip the STANDBY switch DOWN. We then recommend (as
a kindness to the output tubes) waiting at least 1 minute before flipping POWER
switch DOWN hence fully shutting the amp down.
®
ODSm 3/2005
