2. Presentation
The FuelTech FT450 / FT550 Sportsman Data Logging A Harness is a plug
and play solution to easily incorporate data logging into any setup equipped
with an FT450 or FT550 ECU.
It comes pre-terminated to plug directly into essential data logging input
channels (see features below) and has an extra input connector to add up
to two more congurable inputs for sensors or buttons. It is also equipped
with two extra connectors that allow the use of 10 outputs to control EFI fuel
Injectors, ignition control through a CDI box with points input or smart coils (8
coils on wasted spark is not recommended for carbureted V8 applications). The
outputs can also be used to control accessories such as transbrake, shifter,
nitrous, throttle stop, fans, pumps, etc. The harness is set up for either VR or
Hall effect cam and crank sensors and includes 2 relays with built in fuses for
main electronics, injectors and coils. Each connector has its own label and
harness insulation is heat, moisture and oil resistant.
Designed around a Big Block Chevy, yet the harness has extra long leads that
allow it to be used in numerous other applications.
Features:
- FT450 Connector (FT550 A connector)
- CPC Firewall Connector
- Pre-terminated connections:
- Wide Band 02 Sensor x2
- Oil Pressure
- Fuel Pressure
- Engine Temperature
- Transmission Temperature
- Drive shaft sensor / 2-step connector
Extra Inputs connector:
- 2 configurable inputs for sensors or
buttons
Extra Outputs connector:
- For DIY expansion to control EFI fuel
injectors or relay activation for accessory
control (transbrake, shifter, nitrous, throttle
stop, fans, pumps, etc)
Ignition Expansion Connector:
- For DIY expansion to control Ignition or
relay activation for accessory control
(transbrake, shifter, nitrous, throttle stop,
fans, pumps, etc).
