REFRIGERANT SYSTEM DIAGRAM
Models : RSW-9RC / ROW-9RC
Models : RSW-12RC / ROW-12RC
Refrigerant pipe
12.7mm(1/2")
Refrigerant pipe
Charging valve
Cooling
Heating
: Flare coupling
3-Way
valve
4-Way
valve
2-Way
valve
Strainer
Compressor
Check valve
Capillary tube
for heating
Capillary tube
for heating and cooling
OUTDOOR UNITINDOOR UNIT
Condenser
Evaporator
Refrigerant pipe
9.52mm(3/8")
Refrigerant pipe
6.35mm(1/4")
Charging valve
3-Way
valve
4-Way
valve
2-Way
valve
Strainer
Compressor
Check valve
Capillary tube
for heating
Capillary tube
for heating and cooling
OUTDOOR UNITINDOOR UNIT
Condenser
Evaporator
6.35mm(1/4")
2003.04.22
- 5 -
