-42-
Reference Guide - Main Unit
5.
If you cannot find the document, open the document
cover, grip the lever to open the Side 2 scanner, and
then remove the document.
6.
Close the Side 2 scanner, then close the document cover.
7.
Lift the document feeder tray and remove the docu-
ment.
8.
Put the document feeder tray back into position.
C2-PC
1.
Pull up the front handle of the top cover and open the
cover until it stops.
2.
Open the left cover until it stops.
3.
Remove the document.
4.
If the document is caught in the entry, remove the
jammed paper from the left cover.
If the document is caught in the exit area, lift the
document feeder tray and pull the document toward
the exit.
To Next Page
