6 Troubleshooting
112
Troubleshooting
6
2
Move the lever A2 in the arrow direction.
3
Remove the jammed paper.
Note • If the paper is torn, make sure no piece of
paper remains inside the machine.
4
Return the lever A2 to the original position.
5
Push the center of the top left cover and close the cover gently.
Paper Jams in Duplex Module
1
While lifting up the release lever (1), gently
open the top left cover (2).
When the Side Tray (optional) is installed
Remove paper from the Side Tray (1), close the
Side Tray (2), and then open the top left cover.
2
Remove the jammed paper.
Note • If the paper is torn, make sure no piece of
paper remains inside the machine.
To Next Page
