Image Quality Trouble

141

Troubleshooting

Text or images

are printed at an

angle.

The paper guides in the paper

tray are not set in the correct

positions.

Adjust the horizontal and vertical paper

guides to the correct positions.

Refer to "Loading Paper" (P.84).
