Fuji Xerox ApeosPort-VII C6688 - Page 216

7 Problem Solving
216
2 Move handle [2c] downwards (1) and handle [2d] upwards (2), and then move handle [2e]
to the right (3).
3 Turn knob [2f] to the right (1), and remove the jammed paper (2).
Note
z
Hold the end of the paper and remove.
4 Return handles [2e] (1), [2d] (2), and [2c] (3) to their original positions.
5 Close the door.
1
2
3
1
2
2
3
1
