Machine Components
43
Product Overview
2
5 Toner cover Open this cover to replace toner cartridges.
6 Front cover Open this cover to access the insides of the machine to clear paper
jams or replace consumables.
7 Tray 1, 2, 3, 4 Load paper here.
8 Bottom left cover Open this cover to access the insides of the machine to clear paper
jams.
If the Tray 6 (HCF2 (2000 sheets)) is installed in the machine, move the
Tray 6 (HCF2 (2000 sheets)) to the left first.
9 Locking casters Used for locking the wheels of the machine. Lock these casters after
moving the machine to its installation site.
10 Tray 6 (optional) Load paper here.
11 Tray 6 top cover Move the Tray 6 (HCF2 (2000 sheets)) to the left and then open this top
cover to clear paper
jams.
12 Tray 5 (Bypass) Used for loading non-standard paper (thick-stock paper, and other
special media) that cannot be loaded in the Trays 1 to 4, and 6.
13 Tray 5 (Bypass) top cover Open the top cover to clear paper jams.
14 Gigabit Ethernet Board
(optional)
Connected to a network cable.
15 10BASE-T / 100BASE-TX
connector
Connected to a network cable. This connector is not available when the
Gigabit Ethernet Board (optional) is installed.
16 USB 2.0 interface
connector (optional)
Connected to a USB cable.
17 Stylus pen Used for touching the touch screen on the control panel to configure
settings.
Note • You can directly touch the touch screen not only with the stylus pen
but also with a finger.
18 Stylus pen holder Stores the stylus pen.
19 Control Panel (Large size
UI)
Provides operation buttons, LED indicators, and a touch screen.
For details, refer to "Large Size UI" (P.60).
No. Component Function
