Product Overview
2
10 <Stop> button Press this button to pause the current job or communications.
11 <Start> button Press this button to start scanning a document.
12 <Main Power> indicator Lights up when the main power is switched on.
Note • If the main power is not switched on, the machine will not be powered on
even when the power is switched on.
13 <Error> indicator Blinks if a system error occurs.
This indicator lights up when a problem other than a system error occurs
with the machine, including paper jams and running out of paper or toner.
14 <Data> indicator Blinks when the machine is sending or receiving data to or from a client.
This indicator lights up when data is stored in the machine's memory, when
received faxes are waiting to be printed, or when faxes are stored in a folder.
15 <Speed Dial> button Press this button to specify a recipient with an address number when
sending a fax or e-mail.
16 <C (Clear)> button Press this button to cancel a numerical value you have entered with the
numeric keypad.
17 <Dial Pause> button Press this button to insert a pause into a destination number.
18 Numeric keypad Use the numeric buttons on the keypad to enter the number of copies,
passcodes, and other numerical values.
19 <Custom Button 1> (Copy) "Copy" is assigned to this button by default.
Press this button to display the [Copy] screen.
20 <Custom Button 2> (Fax) "Fax" is assigned to this button by default.
Press this button to display the [Fax] screen.
Note • The Fax Kit (optional) must be installed to use this button for Fax service.
21 <Custom Button 3> (Review) "Review" is assigned to this button by default.
On the [Review] screen, you can check a list of the status of Copy, Fax, and
Scan services whose settings have been changed from the defaults. You can
also check the details of fax and e-mail recipients.
22 USB memory slot Insert a USB 2.0 memory device directly here.
Important •A memory card reader cable or a USB memory device cable cannot be
directly connected to the machine. Use the USB Hub (optional) to
connect a memory card reader or a USB memory device cable.
Note • This feature is not available for some models. An optional component is
required. For more information, contact our Customer Support Center.
23 Paper clip tray Used for placing paper clips and staples.
No. Component Function
