Appendix
752
Appendix
16
4
Select [Save].
5
Select [Close].
6
Check the sample printout, and adjust the position if it is misaligned.
If the printing position of the sample image is correct, a line is printed at a position 15 mm
from the edge of the paper. If the position of the line is misaligned, adjust it.
z
A dark black patch is printed on the image of side 1 and a light black patch is printed on the image of side 2
of the sample printed with [Sample Printout]. A color patch is printed to show the paper feed direction.
z
When adjusting multiple types of misalignments, adjust them in the following order: Perpendicularity > Slow
Scan % > Lead/Side Registration
z
For more information on each type of adjustment, refer to the following sections:
z
For Perpendicularity, refer to "Perpendicularity" (P.754)
z
For Slow Scan %, refer to "Slow Scan %" (P.754)
z
For Lead/Side Registration, refer to "Lead/Side Registration" (P.755)
7
After you complete adjustment, print another sample printout and check the adjustment
results.
8
Adjust the paper registration again if necessary.
9
Select [Save] until the tray setting screen is displayed.
10
Select a tray to assign the Adjust Paper Registration settings, and select [Save].
z
If you select [Save] during [Not set] tray is selected, an error message is displayed on the control panel. In this
case, set the Adjust Paper Registration value, selecting a tray not set.
11
Select [Save] until the menu screen is displayed.
To Next Page
