FujiFilm X-T20 User Manual

225
The Setup Menus
8
BUTTON/DIAL SETTING
N
Function button assignment options can also be ac-
cessed by holding the DISP/BACK button. The selector can
not be assigned more than one role at a time.
AF-ON
If AF-ON is selected, you can press the control in-
stead of keeping the shutter button pressed halfway.
MODELING FLASH
If MODELING FLASH is selected when a compatible
shoe-mounted  ash unit is attached, you can press
the control to test- re the  ash and check for shad-
ows and the like (modeling  ash).
TTL-LOCK
If TTL-LOCK is selected, you can press the control to
lock  ash output according to the option selected for
F FLASH SETTING> TTL-LOCK MODE (
P
166).

FujiFilm X-T20 Specifications

General

Megapixels	24.3 MP
ISO Range	200-12800 (expandable to 100-51200)
Continuous Shooting Speed	8 fps
Weight	383 g (including battery and memory card)
Image Processor	X-Processor Pro
Wireless Connectivity	Wi-Fi
Battery	NP-W126S Li-ion battery
Dimensions	118.4 x 82.8 x 41.4 mm
Sensor	APS-C X-Trans CMOS III
Autofocus Points	91 points
Screen	3.0-inch tilting LCD (1.04M dots)
Viewfinder	0.39-inch OLED (2.36M dots)
Video Resolution	4K at 30 fps, Full HD at 60 fps
Battery Life	Approx. 350 shots
Shutter Speed	1/4000 sec to 30 sec
