FujiFilm X-T20 User Manual

259
Peripherals and Optional Accessories
10
External Flash Units
SYNC TERMINAL
SYNC TERMINAL is displayed
if the built-in  ash is lowered
and either no  ash unit, or
an incompatible  ash unit, is
mounted on the hot shoe.
MODE
SYNC TERMINAL
ADJUST
END
Setting
Setting
Description
Description
A
Flash
control
mode
Choose from the following options:
•
M: A trigger signal is transmitted from the sync terminal
and hot shoe when a picture is taken. Choose a shutter
speed slower than the sync speed; even slower speeds
may be required if the unit uses long fl ashes or has a
slow response time.
•
OFF: The sync terminal and hot shoe do not transmit a
trigger signal.
B
Sync
Choose whether the fl ash is timed to fi re immediately
after the shutter opens (H/1ST CURTAIN) or immediately
before it closes (I/2ND CURTAIN). 1ST CURTAIN is recom-
mended in most circumstances.

FujiFilm X-T20 Specifications

General

Megapixels	24.3 MP
ISO Range	200-12800 (expandable to 100-51200)
Continuous Shooting Speed	8 fps
Weight	383 g (including battery and memory card)
Image Processor	X-Processor Pro
Wireless Connectivity	Wi-Fi
Battery	NP-W126S Li-ion battery
Dimensions	118.4 x 82.8 x 41.4 mm
Sensor	APS-C X-Trans CMOS III
Autofocus Points	91 points
Screen	3.0-inch tilting LCD (1.04M dots)
Viewfinder	0.39-inch OLED (2.36M dots)
Video Resolution	4K at 30 fps, Full HD at 60 fps
Battery Life	Approx. 350 shots
Shutter Speed	1/4000 sec to 30 sec
