Fujitsu AB*18LBAJ User Manual

- (01 - 44) -
MULTI TYPE 2ROOM TYPE MULTI TYPE 2ROOM TYPE
MODEL : AR 14L
Q-h Characteristic curve
Cooling capacity(%) STATIC PRESSURE(Pa)Heating capacity(%)
COOLING
Air temperature(
°C)
Air temperature(
°C)
AIR FLOW (m
3
/h)
AIR FLOW (m
3
/h)
AIR FLOW (m
3
/h)
HEATING
0 20 40
m
3
/h
880 792 704
l/s 244 220 196
CFM 518 466 414
m
3
/h
770 693 616
l/s 214 193 171
CFM 453 408 363
m
3
/h
640 576 512
l/s 178 160 142
CFM 377 339 301
FAN SPEED
Hi
Med
Low
Static pressure (Pa)
0
5
10
15
20
25
30
35
40
45
400 500 600 700 800 900 1000
Hi
Med
Low
76.0
80.0
84.0
88.0
92.0
96.0
100.0
104.0
400 500 600 700 800 900 1,000
9.0
10.0
11.0
12.0
13.0
14.0
15.0
16.0
Air temp
Capacity
76.0
80.0
84.0
88.0
92.0
96.0
100.0
104.0
400 500 600 700 800 900 1,000
34.0
36.0
38.0
40.0
42.0
44.0
46.0
48.0
Air temp
Capacity

Fujitsu AB*18LBAJ Specifications

General

Brand	Fujitsu
Model	AB*18LBAJ
Category	Air Conditioner
Language	English
