Top view
Front view
Side view
Bottom view
Drain pipe
mounting place
( 20)
189
177
347
540
31566790
121
578
320
10
184
4- 10mm hole
OUTDOOR UNIT
AOY_24LA_L
Unit : mm
Air flow
2008.06.26 4
