Fujitsu AO G09KATA Series Design & Technical Manual

Model: ASYG07KMCE
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
-5.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
0.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
5.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
15.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
20.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
25.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
30.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
35.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
40.0 1.62 0.75 1.83 0.86 1.93 0.99 2.07 1.11 2.21 1.22 2.28 1.39
46.0 1.28 0.47 1.45 0.54 1.53 0.62 1.64 0.70 1.75 0.76 1.81 0.87
Model: ASYG09KMCE
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
-5.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
0.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
5.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
10.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
15.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
20.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
25.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
30.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
35.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
40.0 2.08 0.97 2.35 1.10 2.47 1.27 2.65 1.42 2.83 1.56 2.92 1.79
46.0 1.64 0.61 1.86 0.69 1.96 0.79 2.10 0.89 2.24 0.98 2.31 1.12
Model: ASYG12KMCE
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
-5.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
0.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
5.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
10.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
15.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
20.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
25.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
30.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
35.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
40.0 2.79 1.30 3.15 1.48 3.32 1.70 3.56 1.91 3.80 2.09 3.92 2.40
46.0 2.21 0.81 2.50 0.93 2.63 1.07 2.82 1.20 3.01 1.31 3.11 1.50
Model: ASYG14KMCE
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
-5.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
0.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
5.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
10.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
15.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
20.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
25.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
30.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
35.0 3.92 2.20 4.43 2.51 4.67 2.89 5.00 3.25 5.35 3.55 5.51 4.07
40.0 3.24 1.51 3.67 1.72 3.87 1.98 4.14 2.23 4.42 2.43 4.56 2.79
46.0 2.57 0.95 2.90 1.08 3.06 1.24 3.28 1.40 3.50 1.53 3.61 1.75
- 411 -
6-2. Cooling capacity
6. Capacity table
