Item no. Part no. Part name Service part
50 9387587227 Base assy ♦
51 9388139012 Pipe bracket A ♦
52 9334143001 Under cover C ♦
53 9334137000 Screw cap ♦
54 9383765056 WLAN adapter holder assy ♦
55
9711732217 Main PCB (For 07 model) ♦
9711732224 Main PCB (For 09 model) ♦
9711732231 Main PCB (For 12 model) ♦
9711732248 Main PCB (For 14 model) ♦
56 9387488029 Cable guide ♦
57 9901013010 Terminal ♦
58 9383729041 Wire cover assy ♦
59 9711146021 Display assy ♦
60 9711147028 Indicator PCB ♦
61
9603688028 Brushless motor (For 07—12 models) ♦
9603492021 Brushless motor (For 14 model) ♦
62 9387589047 Motor case assy ♦
63 9317250009 Air clean filter assy ♦
64 9332911008 Electric filter holder ♦
65
9387593211 Evaporator total assy (For 07—12 models) ♦
9387593204 Evaporator total assy (For 14 model) ♦
66 9900627065 Thermistor assy ♦
67 9387467017 Room thermistor holder ♦
68 9333628004 Bearing D assy ♦
69 9333606033 Crossflow fan assy ♦
— 9901010071
Wire with connector
(CN75 on Main PCB—WLAN adapter [option])
♦
a — Box shield —
b — Control box —
c — PCB holder A —
d — Control cover —
e — Display case assy —
f — Motor case —
g — Motor cover —
3-4. Wall mounted type - (02-43) - 3. Indoor unit parts list
