Item no. Part no. Part name Service part
50
9387587098 Base assy (for 07-14KETA model) ♦
9387587104 Base assy (for 07-14KETA-B model) ♦
51 9383765056 WLAN adapter holder assy ♦
52
9711732293 Main PCB (for 07 model) ♦
9711732309 Main PCB (for 09 model) ♦
9711732316 Main PCB (for 12 model) ♦
9711732323 Main PCB (for 14 model) ♦
53 9387488012 Cable guide ♦
54 9711382009 Display assy ♦
55 9711358004 Display PCB ♦
56 9901013010 Terminal ♦
57 9384500014 Motor case sub assy ♦
58
9603768003 Brushless motor (for 07-12 model) ♦
9603631017 Brushless motor (for 14 model) ♦
59 9387713022 Motor cover assy ♦
60 9317250009 Air clean filter assy ♦
61 9332911008 Electric filter holder ♦
62
9387593143 Evaporator total assy (for 07-12 model) ♦
9387593150 Evaporator total assy (for 14 model) ♦
63 9900627041 Thermistor assy ♦
64 9387467000 Room thermistor holder ♦
65 9333628004 Bearing D assy ♦
66 9387055047 Crossflow fan assy ♦
a — Box shield —
b — Control box —
c — PCB holder A —
d — Motion sensor —
e — Front panel cover B assy —
f — Display case assy —
g — Control cover —
3-4. Wall mounted type - (02-51) - 3. Indoor unit parts list
