Item no. Part no. Part name Service part
11 9387476002 Screw cover ♦
12 9323341012 Under cover L ♦
13 9323342019 Under cover R ♦
14 9387596625 Front panel total assy ♦
3-5. Wall mounted type - (02-38) - 3. Indoor unit parts list
