Wire cover assy
Wire cover B assy
31
32
Item no. Part no. Part name Service part
31 9387479010 Horizontal louver assy ♦
32 9383730030 Louver spring ♦
3-5. Wall mounted type - (02-40) - 3. Indoor unit parts list
