Item no. Part no. Part name Service part
1 9388158013 Bracket panel ♦
2 9387476002 Screw cover ♦
3 9383729027 Wire cover assy B ♦
4 9387597066 Wire cover assy ♦
5 9383765056 WLAN adapter holder assy ♦
6 9387479010 Louver assy (Up/Down) ♦
7 9323342040 Under cover R ♦
8 9317250009 Air cleaning filter assy ♦
9 9332438703 Wireless remote controller ♦
10 9318912005 Remote controller holder ♦
11 9384977137 Front panel total assy ♦
12 9387756111 Intake grille assy ♦
13 9323340008 Air filter ♦
14 9333719009 Grille clamper L ♦
15 9333704005 Grille clamper R ♦
16 9323341043 Under cover L ♦
17 9333608006 Bush ♦
18 9383730030 Louver spring ♦
a — Front panel —
b — Panel cover —
c — Front panel B —
3-5. Wall mounted type - (02-47) - 3. Indoor unit parts list
