Item no. Part no. Part name Service part
50 9383735196 Evaporator total assy ♦
51 9387467000 Room thermistor holder ♦
52 9901013010 Terminal 3P ♦
53
9711732330 Main PCB (18 model) ♦
9711732347 Main PCB (22 model) ♦
9711732354 Main PCB (24 model) ♦
54 9900627041 Thermistor assy ♦
55 9711146052 Display assy ♦
56 9711147011 Indicator PCB ♦
57 9387587159 Base assy ♦
58 9388150000 Pipe bracket A ♦
59 9388155005 Under cover C ♦
60 9388182001 Screw cover ♦
61 9384500007 Motor case sub assy ♦
62 9383565007 Pipe bracket ♦
63 9603631000 DC fan motor ♦
64 9387713015 Motor cover assy ♦
65 9387488012 Cable guide ♦
66 9387714012 Gear case assy ♦
67 9901011016 Stepping motor ♦
68 9383728006 R and L louver SPM assy ♦
69 9901011023 Stepping motor ♦
70 9387590142 Drain pan total assy ♦
71 9316177017 Drain cap ♦
72 9316904002 Drain hose assy ♦
73 9333628004 Bearing D assy ♦
74 9387055054 Crossflow fan assy ♦
— 9901010071
Wire with connector
(USB adapter connection)
♦
a — Control box —
b — Control cover —
c — Display case —
3-5. Wall mounted type - (02-49) - 3. Indoor unit parts list
