Item no. Part no. Part name Service part
50 9387587128 Base assy ♦
51 9388139005 Pipe bracket A ♦
52 9388138008 Under cover C ♦
53 9388182001 Screw cover ♦
54 9383765056 WLAN adapter holder assy ♦
55
9711732255 Main PCB (For 07 model) ♦
9711732262 Main PCB (For 09 model) ♦
9711732279 Main PCB (For 12 model) ♦
9711732286 Main PCB (For 14 model) ♦
56 9387488012 Cable guide ♦
57 9711146038 Display assy ♦
58 9711147011 Indicator PCB ♦
59 9317755061 Pyroelectric sensor ♦
60 9382134006 Front panel cover B assy ♦
61 9901013010 Terminal ♦
62 9384500014 Motor case sub assy ♦
63
9603768003 DC fan motor (For 07 and 09 model) ♦
9603631017 DC fan motor (For 12 and 14 model) ♦
64 9387713022 Motor cover assy ♦
65 9317250009 Air clean filter assy ♦
66
9387593334 Evaporator total assy (For 07 and 09 model) ♦
9387593426 Evaporator total assy (For 12 and 14 model) ♦
67 9900627041 Thermistor assy ♦
68 9387467000 Room thermistor holder ♦
69 9333628004 Bearing D assy ♦
70 9387055047 Crossflow fan assy ♦
— 9709626054
Wire with connector
(CN10 on Main PCB—Pyroelectric sensor)
♦
— 9901010071
Wire with connector
(USB adapter connection)
♦
a — Box shield —
b — Control box —
c — PCB holder A —
d — Control cover —
e — Display case assy —
3-5. Wall mounted type - (02-36) - 3. Indoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
