Fujitsu AO G09KBTB Series Design & Technical Manual

AOYG30KBTA4
Combination no. Unit 1 Unit 2 Unit 3 Unit 4 Total
51 9 14 14 — 37
52 9 14 18 — 41
53 9 14 22 — 45
54 9 14 24 — 47
55 9 18 18 — 45
56 12 12 12 — 36
57 12 12 14 — 38
58 12 12 18 — 42
59 12 12 22 — 46
60 12 12 24 — 48
61 12 14 14 — 40
62 12 14 18 — 44
63 12 18 18 — 48
64 14 14 14 — 42
65 14 14 18 — 46
66 7 7 7 7 28
67 7 7 7 9 30
68 7 7 7 12 33
69 7 7 7 14 35
70 7 7 7 18 39
71 7 7 9 9 32
72 7 7 9 12 35
73 7 7 9 14 37
74 7 7 9 18 41
75 7 7 12 12 38
76 7 7 12 14 40
77 7 7 12 18 44
78 7 7 14 14 42
79 7 7 14 18 46
80 7 9 9 9 34
81 7 9 9 12 37
82 7 9 9 14 39
83 7 9 9 18 43
84 7 9 12 12 40
85 7 9 12 14 42
86 7 9 12 18 46
87 7 9 14 14 44
88 7 9 14 18 48
89 7 12 12 12 43
90 7 12 12 14 45
91 7 12 12 18 49
92 7 12 14 14 47
93 9 9 9 9 36
94 9 9 9 12 39
95 9 9 9 14 41
96 9 9 9 18 45
97 9 9 12 12 42
98 9 9 12 14 44
99 9 9 12 18 48
100 9 9 14 14 46
101 9 12 12 12 45
102 9 12 12 14 47
103 9 12 14 14 49
104 12 12 12 12 48
- 5 -
1-1. Indoor unit connection patterns
1. Model lineup
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE
