Fujitsu AO G09KBTB Series Design & Technical Manual

• Operation status
– Compact cassette type
On
0.5°C
-0.5°C
On
12 V
On
Off
Off
0 V
Off
Heating operation
Heater
Fan
Comp. On/Off
Room temperature
Set temp.
3 min or more
– Slim duct type
On
0.5°C
-0.5°C
On
12 V
On
Off
Off
0 V
Off
Heating operation
Heater
Fan
Comp. On/Off
Room temperature
Set temp.
3 min or more
1 min 1 min
On
Off
DIP-SW101-3 On
DIP-SW101-3 Off
NOTE: In following operations, compressor will be on.
• Other than heating
• Test run
- 236 -
12-5. Wall mounted type (KGTE, KGTF, KMTE, KMCE, KMCF, KETE, KETE-B, KETF, and
KETF-B)
12. External input and output
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE

Fujitsu AO G09KBTB Series Specifications

General

Brand	Fujitsu
Model	AO G09KBTB Series
Category	Air Conditioner
Language	English
