Fujitsu AO G09KBTB Series User Manual

¢ 2-way valve thermistor, 3-way valve thermistor
Temperature (°C) Resistance (kΩ) Voltage (V)
-30.0 1,013.11 0.18
-25.0 729.09 0.25
-20.0 531.56 0.34
-15.0 392.31 0.44
-10.0 292.91 0.58
-5.0 221.09 0.74
0.0 168.60 0.93
5.0 129.84 1.14
10.0 100.91 1.38
15.0 79.12 1.63
20.0 62.55 1.90
25.0 49.84 2.17
30.0 40.01 2.45
35.0 32.35 2.71
40.0 26.34 2.96
45.0 21.58 3.20
50.0 17.79 3.41
55.0 14.75 3.61
60.0 12.30 3.78
65.0 10.32 3.94
70.0 8.69 4.07
75.0 7.36 4.19
80.0 6.27 4.30
85.0 5.36 4.39
90.0 4.60 4.46
95.0 3.96 4.53
100.0 3.43 4.59
105.0 2.98 4.64
110.0 2.60 4.68
115.0 2.27 4.72
120.0 2.00 4.75
6-2. Outdoor unit - (03-94) - 6. Thermistor resistance values
TROUBLESHOOTING TROUBLESHOOTING

Fujitsu AO G09KBTB Series Specifications

General

Brand	Fujitsu
Model	AO G09KBTB Series
Category	Air Conditioner
Language	English
