Fujitsu AO G12KATA Series Service Manual

¢ Wall mounted type (For KMTB, KMTE, KMCC, and KMCE)
 Fan speed
Indoor fan speed is defined as below.
Operation mode Fan mode
Speed (rpm)
ASHG07KMCC
ASHG07KMCE
ASHG09KMCC
ASHG09KMCE
ASHG12KMCC
ASHG12KMCE
ASHG14KMCC
ASHG14KMCE
Heating
POWERFUL 1,230 1,270 1,310 1,400
HIGH 1,160 1,200 1,240 1,330
MED+ 1,060 1,060 1,120 1,160
MED 970 990 1,050 1,100
LOW 820 830 900 910
QUIET 650 650 650 670
Cool air
prevention
570 570 570 580
S-LOW 420 420 420 470
Cooling/
Fan
POWERFUL 1,140 1,200 1,200 1,320
HIGH 1,070 1,130 1,130 1,250
MED 920 940 940 1,020
LOW 780 780 780 810
QUIET 630 630 630 630
Soft quiet
490*
1
490*
1
490*
1
510*
1
S-LOW
420*
2
420*
2
420*
2
470*
2
Dry
X zone: 630
J zone: 630
X zone: 630
J zone: 630
X zone: 630
J zone: 630
X zone: 630
J zone: 630
Operation mode Fan mode
Speed (rpm)
ASHG07KMTB ASHG09KMTB ASHG12KMTB ASHG14KMTB
Heating
POWERFUL 1,210 1,250 1,270 1,360
HIGH 1,140 1,180 1,200 1,290
MED+ 1,040 1,040 1,100 1,160
MED 950 970 1,030 1,100
LOW 800 810 880 910
QUIET 630 630 630 670
Cool air
prevention
550 550 550 580
S-LOW 400 400 400 470
Cooling/
Fan
POWERFUL 1,120 1,180 1,180 1,320
HIGH 1,050 1,100 1,110 1,250
MED 900 920 920 1,020
LOW 760 760 760 810
QUIET 550 550 550 580
Soft quiet
470*
1
470*
1
470*
1
510*
1
S-LOW
400*
2
400*
2
400*
2
470*
2
Dry
X zone: 550
J zone: 550
X zone: 550
J zone: 550
X zone: 550
J zone: 550
X zone: 580
J zone: 580
