AR-REM4E (for Wall mounted type KGTB), AR-REW3E (for Wall
mounted type KGTE), AR-REW4E (for Wall mounted type KETA
and KETE), AR-REW2E (for Wall mounted type KMTB and
KMTE), and AR-REM7E (for Floor type)
 Button name and function
During address setting mode, indoor unit reject the any operation command from remote con-
troller.
10°C HEAT button
Setting number
Function number
Refer to Function details
Refer to Function details
Switches between the setting number
(bottom line) and function number (top
line)
The displayed number Increases and
decreases
Changes the display digits
Transmits function setting
Transmits function mode
POWERFUL button
SET TEMP. (
/ ) button
START/STOP ( ) button
RESET button
MODE button
NOTE:
The number of buttons varies by the remote controller model.
1-2. Indoor unit (setting by wireless remote controller)
- (05-4) - 1. Function settings (for indoor unit)
FIELD
WORKING
FIELD
WORKING
To Next Page
