Page #33 background image
Item no. Part no. Part name Service part
1 9383880001 Top panel assy
2 9381013005 Protective net
3 9375361013 Net rubber
4 9900984038 Thermistor (Heat exchanger)
5 9900727154 Thermistor assy
6 9383607004 Thermo holder
7 9383874017 Right panel sub assy
8 9383879005 Rear pipe cover
9
9711424020 Inverter PCB (for 45 model)
9711424013 Inverter PCB (for 54 model)
10 9900634025 Reactor assy
11 9901053016 Terminal
12
9711431127 Main PCB (Service) (for 45 model)
9711431141 Main PCB (Service) (for 54 model)
13 313166024302 Drain cap
14 9303029015 Drain assy
15 9350255009 Base assy (Service)
16 9383876011 Service panel sub assy
17 9383878008 Front pipe cover
18 9351355005 Emblem rear
19 9383863011 Front panel assy
20 9383604003 Blow grille
21 9383689000 Blow grille insulation
22 9383882012 Left panel sub assy
23 9383336003 Propeller fan
24 9603733018 Brushless motor
25 9383862021 Motor bracket assy
26 9374420636 Condenser sub assy
a Separate wall assy
b Control box unit
4-2. Models: AOYG45KQTA and AOYG54KQTA - (02-15) - 4. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
