Fujitsu AOU24RLXFZ Design & Technical Manual

 Indoor units: 9,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 10.98 1.31 10.63 1.35 10.27 1.39 9.91 1.43 9.70 1.45
14 12 12.49 1.41 12.10 1.45 11.69 1.49 11.28 1.54 11.03 1.56
23 19 13.18 1.37 12.77 1.41 12.33 1.45 11.90 1.49 11.64 1.51
32 28 13.95 1.32 13.51 1.36 13.05 1.40 12.60 1.44 12.32 1.46
41 37 15.80 1.27 15.30 1.31 14.78 1.34 14.27 1.38 13.95 1.41
47 43 16.85 1.28 16.32 1.32 15.77 1.36 15.21 1.40 14.88 1.42
50 47 16.98 1.30 16.44 1.33 15.88 1.37 15.33 1.41 14.99 1.43
59 50 17.14 1.29 16.60 1.33 16.04 1.37 15.48 1.41 15.14 1.43
68 59 16.81 0.98 16.28 1.01 15.73 1.04 15.18 1.07 14.84 1.08
75 65 13.33 0.79 12.91 0.81 12.47 0.84 12.03 0.86 11.77 0.88
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 3.22 1.31 3.12 1.35 3.01 1.39 2.91 1.43 2.84 1.45
-10.0 -11.1 3.66 1.41 3.55 1.45 3.43 1.49 3.31 1.54 3.23 1.56
-5.0 -7.2 3.86 1.37 3.74 1.41 3.61 1.45 3.49 1.49 3.41 1.51
0.0 -2.2 4.09 1.32 3.96 1.36 3.83 1.40 3.69 1.44 3.61 1.46
5.0 2.8 4.63 1.27 4.48 1.31 4.33 1.34 4.18 1.38 4.09 1.41
8.3 6.1 4.94 1.28 4.78 1.32 4.62 1.36 4.46 1.40 4.36 1.42
10.0 8.3 4.98 1.30 4.82 1.33 4.66 1.37 4.49 1.41 4.39 1.43
15.0 10.0 5.02 1.29 4.87 1.33 4.70 1.37 4.54 1.41 4.44 1.43
20.0 15.0 4.93 0.98 4.77 1.01 4.61 1.04 4.45 1.07 4.35 1.08
23.9 18.3 3.91 0.79 3.78 0.81 3.65 0.84 3.53 0.86 3.45 0.88
 Indoor units: 12,000 Btu
Indoor temperature
°FDB 60 65 70 75 78
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
5 3 12.55 1.69 12.15 1.74 11.74 1.79 11.33 1.84 11.08 1.87
14 12 14.28 1.81 13.83 1.86 13.36 1.92 12.89 1.97 12.61 2.00
23 19 15.06 1.78 14.58 1.83 14.09 1.88 13.59 1.93 13.29 1.96
32 28 15.94 1.69 15.44 1.74 14.92 1.79 14.40 1.84 14.08 1.87
41 37 18.06 1.58 17.49 1.63 16.89 1.67 16.30 1.72 15.94 1.75
47 43 19.26 1.60 18.65 1.64 18.02 1.69 17.39 1.74 17.00 1.76
50 47 19.40 1.61 18.79 1.66 18.15 1.71 17.52 1.76 17.13 1.78
59 50 19.59 1.62 18.97 1.66 18.33 1.71 17.69 1.76 17.30 1.79
68 59 19.21 1.37 18.60 1.41 17.97 1.45 17.34 1.49 16.96 1.52
75 65 16.21 0.95 15.70 0.98 15.16 1.00 14.63 1.03 14.31 1.05
Indoor temperature
°CDB 15.6 18.3 21.2 23.9 25.6
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15.0 -16.1 3.68 1.69 3.56 1.74 3.44 1.79 3.32 1.84 3.25 1.87
-10.0 -11.1 4.18 1.81 4.05 1.86 3.92 1.92 3.78 1.97 3.70 2.00
-5.0 -7.2 4.41 1.78 4.27 1.83 4.13 1.88 3.98 1.93 3.90 1.96
0.0 -2.2 4.67 1.69 4.53 1.74 4.37 1.79 4.22 1.84 4.13 1.87
5.0 2.8 5.29 1.58 5.12 1.63 4.95 1.67 4.78 1.72 4.67 1.75
8.3 6.1 5.64 1.60 5.47 1.64 5.28 1.69 5.10 1.74 4.98 1.76
10.0 8.3 5.69 1.61 5.51 1.66 5.32 1.71 5.13 1.76 5.02 1.78
15.0 10.0 5.74 1.62 5.56 1.66 5.37 1.71 5.18 1.76 5.07 1.79
20.0 15.0 5.63 1.37 5.45 1.41 5.27 1.45 5.08 1.49 4.97 1.52
23.9 18.3 4.75 0.95 4.60 0.98 4.44 1.00 4.29 1.03 4.19 1.05
- 191 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOU18RLXFZ OUTDOOR UNIT AOU18RLXFZ

Fujitsu AOU24RLXFZ Specifications

General

Brand	Fujitsu
Model	AOU24RLXFZ
Category	Air Conditioner
Language	English
