- 3 -
MULTI TYPE 2-3 rooms type
 Indoor unit connection patterns
 2 rooms
7: 7,000Btu/h, 9: 9,000Btu/h, 12: 12,000Btu/h
 3 rooms
7: 7,000Btu/h, 9: 9,000Btu/h, 12: 12,000Btu/h, 15: 14,000Btu/h, 18: 18,000Btu/h,
AOU18RLXFZH
No. Room 1 Room 2 Total
17714
27916
371219
49918
591221
AOU24RLXFZH
No. Room 1 Room 2 Room 3 Total
177—14
279—16
3712—19
4715—22
5718—25
699—18
7912—21
8915—24
9918—27
10 12 12 — 24
11 12 15 — 27
12 7 7 7 21
13 7 7 9 23
14 7 7 12 26
15 7 9 9 25
16 9 9 9 27
