24
22
21
28
INDOOR UNIT
Control box
12
26
Terminal
9900720001
Main PCB (09)
9709170076
25
Earth Terminal
9332553024
21
Control Box
9332554007
22
Cover Shield
9332542011
23
Box Shield Assy
9332561005
24
Main PCB (12)
9709170083
24
28
Room Thermistor Holder
9316895003
Ref.
Description
Part number
27
29
Thermistor Assy
9900714017
Display Assy
9709173015
27
29
23
25
26
2012.10.30
12
14
Table of Contents
Table of Contents
1
Room Air Conditioner
1
Wall Mounted Type
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
Outdoor Pcb Circuit Diagram
9
Error Detection
11
Parts (Indoor Unit)
12
Parts (Outdoor Unit)
17
Accessories
21
