Evaporator Total Assy (09)
9316893085
52
Evaporator Total Assy (12)
9316893092
56 Rear Bracket 9332540017
54
53
9332538007
55 Evaporator Holder L
Evaporator Holder R
9332539004
Earth Terminal 9316579002
57 Filter Guide 9332541007
Ref. Description Part number
51
52
INDOOR UNIT
Evaporator
ASU9RL2
ASU12RL2
54
55
57
2012.07.12
