When you order parts, please make a photocopy of this page and
fill the number of the parts in the "Order" column.
2 Fan Guard 9371187013 9371187013
4 Emblem-Rear 9351355005 9351255005
5 Front Panel, Painted 9371924014 9371924014
7 Connector Cover (Cabinet) 9366398004 9366398004
12 Base Assy, Painted 9371920078 9371920078
13-2 2-Way Valve 9372204054 9372204023
13-3 3-Way Valve 9372205051 9372205075
14 Valve Cover 9372796016 9372796016
15 Condenser Sub Assy 9372313183 9372313183
16 Condenser Assy 9372181096 9372181096
17 Thermistor Holder Pipe 313714262805 313714262805
26-1 Compressor Cover-A 9373730019 9374430055
26-2 Compressor Cover-B 9373730026 9374431052
29 Separate Wall 9372795019
9372795019
31 Controller PCB Assy 9705285064
9705285071
---- ACTPM 9703457012 9703457012
---- Capacitor, Elec. 9705387010 9705387010
33 Control Cover 9372792018
9372792018
---- Fuse 0600086039 0600086039
---- Fuse Holder 0501454012 0501454012
---- Capacitor, Plastic 9900270049 9900270049
---- Terminal-5P 9900203023 9900203023
---- Terminal-2P 9701971015 9701971015
39 Propeller Fan Assy 9366378013
9366378013
41 Fan Motor Assy-IN 9601671046
9601671046
45-1 Motor Bracket 9371929019
9371929019
45-2 Motor Bracket-Top 9371931012
9371931012
45-3 Motor Bracket-Center 9371930015 9371930015
45-4 Motor Bracket-Bottom 9371932019 9371932019
46 Compressor Assy 9373262015 9373262015
55 Special Nut M8 9355091008 9355091008
64 Side Panel-L, Painted 9371926018 9371926018
---- Hex. Bolt Socket 0700145148 0700145148
85 Valve Plate, Painted 9371928012 9371928012
108 Rubber Seat (For Comp. ) 9358080009 9358080009
109 Terminal Cover (For Comp. ) 9373264019 9373264019
---- Clip (Cable) 9352715006 9352715006
---- BR Sheet 9363708042 9363708042
---- Relay 9900117016 9900117016
273-1 Strainer Assy 9372524015 9372524015
273-2 Joint Pipe (2-Way)-A 9373729549 9373729495
334 Accumulator 9368391003 9368391003
335 Accumulator Holder Rubber 9354022010 9354022010
343 Solenoid 9900165079 9900165079
344 4-Way Valve 9900163013 9900163013
345-1 Muffler 9372369029 9372369029
345-2 Joint Pipe (3-Way) 9373729556 9373729501
346-1 Expansion Valve Assy 9373729518 9373729518
346-2 Coil (Expansion Valve) 9900057022 9900057022
348 Pressure Switch Assy 9373729044 9373729044
349 Capillary Assy 9373729433 9373729433
361 Accumulator Support Assy 9372252017 9372252017
411 Gasket 9373266013 9373266013
527 Protective Net 9371934013 9371934013
734 Top Plate 9371925011 9371925011
754 Rubber Washer 9358078006 9358078006
---- Compressor Presure Switch 9900186012 9900186012
---- Compressor Thermal Switch 9373263012 9373263012
---- Discherge Temperature Thermistor 9704219039 9704219039
---- Heat Exchanger Thermistor 9900374020 9900374020
---- Outdoor TemperatureThermistor 9900378011 9900378011
---- Heat Sink Thermistor 9900195014 9900195014
OUTDOOR UNIT
Ref.
No.
Description
AOY12LMAKL AOY14LMAKL
Ord.
Q'ty
Part No.
172006.04.24
