INDOOR UNIT
132008.01.10
PARTS
1
2
2
3
4
8
6
6
9
1 Intake Grille Assy
2 Rope Assy
3 Panel (Front) L
4 Panel (Front) R
6 Air Clean Filter Assy
Parts numberDescriptionRef
9316418011
9316458017
9316187016
9316186019
9312152018
Remote Control Holder
-- 9305642045
-- Remote Control 9316397019
Bracket Panel9 9316272019
8 Panel (Front) 9316185012
5
5 Air Filter 9316189010
