– 18 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the “Order” column.
AOY24ANA
OUTDOOR UNIT
Ref.
No.
Description Q’ty
2 Fan Cover 9350214020
4 Emblem-Rear “FUJITSU” 9351355005
5 Cabinet-A, Painted 9303876015
6 Cabinet-C, Painted 9353549013
7 Connector Cover 9358011010
8 Wire Assy (Shield)-D 9359904076
9 Cabinet-B, Painted 9303874011
10 Noise Insulation-E 313791106305
12 Base Assy, Painted 9353452054
13 3-Way Valve Assy 9364523002
14 2-Way Valve Assy 9357964010
15 Dryer 9353789006
16 Condenser Assy 9356015010
18 Suction Pipe Assy 9363043013
20 Discharge Pipe 9363042016
26 Compressor Cover-A 9363020007
29 Separate Wall 313986033213
32-1 Control Box Metal-A 9353595003
34 Capacitor (Fan Motor) 9357965017
36 Cord Holder Metal 9356934007
37 Running Capacitor 9703107016
38 Capacitor Clamp Metal 9351770013
39 Propeller Fan Assy 9300855013
Part No.
Ref.
No.
Description Q’ty
41 Fan Motor Assy-Out 9600738023
45 Motor Fixing Table Assy 313029311100
46 Compressor Assy 9363019001
51 Special Nut M5 (For Comp.) 9300301015
55 Special Nut M8 (For Comp.) 313252257701
67 Rubber (Vibration-proof) 313659068604
107 Rubber Seat-A (For Comp.) 9351049010
109 Terminal Cover (For Comp.) 9351048013
117-3 Hex. Nut w/Sp. Washer 301721180114
187 Clamp No. 1219 313361271706
196-1 Clamp SKB-3M 312300787605
218-3 Power Relay 9353619006
328 Compressor Plate-B 9363049015
338 Motor Fixture Metal 313029297108
348 Outlet Pipe (Cond.) 9363041019
353 Valve-A Assy 9364325002
412 Terminal Gasket 9351051013
646 Compressor Cover-B 9363021004
717 Center Plate 9350216017
754 Terminal Gasket, Washer 9351053017
815 Terminal-5P 9356497021
823-2 Fuse Holder 0500063024
824-4 Fuse 0600222529
Part No.
To Next Page
