– 20 –
Name and Shape Part No.Use
For positioning the indoor unit.
For under ceiling type.
For suspending the indoor unit from ceiling.
For suspending the indoor unit on the wall.
For fixing the wall bracket.
For indoor side pipe joint.
(Large pipe)
For indoor side pipe joint.
(Small pipe)
For fixing the drain hose.
Adhesive type 70 x 230
For fixing the drain hose
L 280 mm
9358536018
9358535011
301171164104
9359107002
9358596005
9358595008
313806339400
301821112213
9358597002
301141164200
9350716012
313209328104
312300787605
9359242000
9359225003
313806350303
}
Tapping screw (ø4 x 10)
Tapping screw (ø4 x 20)
Installation template
Hanger bracket-L
Hanger bracket-R
Anchor bolt (M12)
Special nut
Spring washer
Wall bracket
Cosmetic Panel-L
Cosmetic Panel-R
INDOOR UNIT ACCESSORIES
Coupler heat insulator (large)
Coupler heat insulator (small)
Nylon fastener (small)
Drain hose
Insulation (drain hose)
To Next Page
