– 4 –
Dryer
Cooling
: Flare couping
Refrigerant pipe
ø 15.88 mm (5/8")
Refrigerant pipe
ø 9.53 mm (3/8")
Capillary tube
Charging valve
Compressor
Distributor
OUTDOOR UNITINDOOR UNIT
Condenser
Evaporator
REFRIGERANT SYSTEM DIAGRAM
