Fujitsu AOY24LMAM2 Service Manual

2008.01.21
1
H x W x D
600 x 740 x 200 mm
MEASUREMENT
DIMENSIONS
Gross / Net
17 kg / 14 kg
WEIGHT
SPECIFICATIONS
TYPE
Cooling & heating inverter
MODEL NAME
INDOOR UNIT
AGYF14LACAGYF12LACAGYF09LAC
Cooling
Heating
MOISTURE REMOVAL
1.5 L/hr
AIR CIRCULATION HIGH
650 m3/hr530 m3/hr
650 m3/hr530 m3/hr
0.7 L/hr
500 m3/hr
600 m3/hr
1.1 L/hr
FAN MOTOR
POWER SOURCE
230 V230 V 230 V
High speed
1,330 / 1,120 r.p.m.
Cooling
(upper fan / lower fan)
Med speed
1,100 / 930 r.p.m.
Low speed
890 / 750 r.p.m.
Quiet
660 / 560 r.p.m.
High speed
1,330 / 1,120 r.p.m.
Heating
(upper fan / lower fan)
Med speed
1,140 / 970 r.p.m.
Low speed
940 / 800 r.p.m.
Quiet
660 / 560 r.p.m.
1,240 / 1,050 r.p.m.
1,050 / 890 r.p.m.
860 / 730 r.p.m.
660 / 560 r.p.m.
1,240 / 1,050 r.p.m.
1,080 / 920 r.p.m.
910 / 770 r.p.m.
660 / 560 r.p.m.
1,120 / 950 r.p.m.
960 / 820 r.p.m.
820 / 700 r.p.m.
660 / 560 r.p.m.
1,120 / 950 r.p.m.
1,000 / 850 r.p.m.
860 / 730 r.p.m.
660 / 560 r.p.m.
ELECTRICAL DATA
Cooling / Heating
Quiet
Low speed
22 dB(A) / 22 dB(A)
31 dB(A) / 33 dB(A)
Med speed
High speed
38 dB(A) / 39 dB(A)
44 dB(A) / 44 dB(A)
22 dB(A) / 22 dB(A)
30 dB(A) / 30 dB(A)
35 dB(A) / 35 dB(A)
39 dB(A) / 39 dB(A)
22 dB(A) / 22 dB(A)
30 dB(A) / 32 dB(A)
36 dB(A) / 38 dB(A)
42 dB(A) / 42 dB(A)
NOISE LEVEL

Fujitsu AOY24LMAM2 Specifications

General

Brand	Fujitsu
Model	AOY24LMAM2
Category	Air Conditioner
Language	English
