Models : ASY30FBBJ / AOY30FNBDL
Models : ASY30UBBJ / AOY30UNBDL
Refrigerant pipe
Refrigerant pipe
Cappillary tube
Condenser
Evaporater
Evaporater
CondenserAccumulator
Accumulator
Charging valve
Charging valve
Strainer
PRESSURE
CHECK
VALVE
PRESSURE
CHECK
VALVE
9.52mm(3/8")
Refrigerant pipe
9.52mm(3/8")
15.88mm(5/8")
Strainer
Cappillary tube
Strainer
Condenser
Compressor
2003.12.29 3
4-Way valve
2-Way
valve
3-Way
valve
3-Way
valve
3-Way
valve
Refrigerant pipe
Cooling
Refrigerant direction
Heating
INDOOR UNIT OUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
15.88mm(5/8")
Distributor
Distributor
REFRIGERANT SYSTEM DIAGRAM
