Fujitsu AOY30LMAL User Manual

SWITCHING
SWITCHING
SWITCHING
SWITCHING
CORRECTION
CORRECTION
HEAT EXCHANGER THERMISTOR
OPERATE
INDICATOR PCB
MANUAL AUTO
SWITCH
INDOOR PRINTED CIRCUIT BOARD
CIRCUIT DIAGRAM
Jumper wire configurations
Switch Function ON/Linked
JM1 High ceiling (See table 5) standard High Ceiling 1
JM2 / JM3 Custom code (See table 2)
JM4 Auto restart enable disable
JM5 / JM6 Heating compensation (See table 1)
Table 1
ON / ON +4 A
ON / OFF -2 B
OFF / ON 0 C
OFF / OFF +2 D
ROOM TEMPERATURE THERMISTOR
OFF/Open
Table 2
ON / ON
ON / OFF
OFF / ON
OFF / OFF
72004.11.12
CONTROLLER PCB ASSEMBLY (MAIN PCB)
AWY24LBAJ : EZ-0021HHSE-C
AWY30LBAJ : EZ-0021GHSE-C
Models :
AWY24LBAJ
AWY30LBAJ
