DIMENSIONS
(Unit : mm)
INDOOR UNIT
2005.06.23 3
Models : AUY30LUAS
AUY36LUAS
AUY45LUAS
30
296
750
60
(Drain pipe)
120
285
250
(Large pipe)
(Small pipe)
150
298.5
305.5 248.5
60
(Drain pipe)
120
(Large pipe)
(Small pipe)
150
298.5
305.5 248.5
Drain Inside Dia. 32
Outside Dia. 37
750
940
940
