ADDITIONAL REFRIGERANT CHARGE (R410A)
Pipe Length 7.5 m (25 ft) 2,300 g (81.1 oz) 2,300 g (81.1 oz)
10.0 m (33 ft) 2,350 g (82.9 oz) 2,400 g (84.7 oz)
20.0 m (66 ft) 2,550 g (89.9 oz) 2,800 g (98.8 oz)
30.0 m (99 ft)
2,750 g (97.0 oz) 3,200 g (112.9 oz)
ADDITIONAL CHARGE
FULL CHARGE
AMOUNT
20 g / m (0.21 oz/ft) 40 g / m (0.43 oz/ft)
SPECIFICATIONS
TYPE
COOLING & HEATING
INDOOR UNIT ABY30LBAG ABY36LBAG
OUTDOOR UNIT AOY30LMBWL AOY36LMBWL
COOLING CAPACITY
(kW)
(kW)
8.50 10.0
HEATING CAPACITY
10.0 10.8
POWER SOURCE
(V) 230
FREQUENCY
RUNNING
(A)
COOLING 13.1 18.0
CURRENT
HEATING 12.7 14.2
INPUT WATTS
(kW)
COOLING 3.0 4.12
HEATING 2.90 3.26
E.E.R.
(kW/kW)
COOLING 2.83 2.43
HEATING 3.45 3.31
MOISTURE REMOVAL
( /hr)
2.5
AIR CIRCULATION
(m
3
/hr) 1,660
3.0
1,850
ELECTRICAL DATA
FAN MOTOR
COMPRESSOR
Hermetic type, 4 poles, Inverter, Twin rotary
TNB220FPBM9
(V) 230
DISCRIMINATION MFA-45DZM
INDOOR
HI-SPEED ( r.p.m. ) 1,000
UNIT
MED-SPEED ( r.p.m. ) 900
LO-SPEED ( r.p.m. ) 750
1,100
1,000
850
OUTDOOR
DISCRIMINATION MFE-60PO
HI-SPEED ( r.p.m. ) 850
UNIT
LO-SPEED ( r.p.m. ) 900
WEIGHT
INDOOR UNIT
NET / GROSS 48 / 61
OUTDOOR UNIT
(kg)
NET / GROSS (kg) 64 / 70
1 50Hz
DIMENSIONS
INDOOR UNIT
H x W x D 240 x 1,660 x 700
OUTDOOR UNIT
(mm)
H x W x D (mm) 830 x 900 x 330
TYPE
DISCRIMINATION
POWER SOURCE
