Fujitsu AOY30LNAWL User Manual

OUTDOOR UNIT
Ref. Ord.
No.
AOY30LNAWL AOY36LNAWL
Q'ty
1 Top Panel Sub Assy 9374417032
2 Front Panel 9374094066
3 Fan Guard 9374330010
4 Grip Side 9374173013
5 Service Panel Sub Assy 9374415052
6 Right Panel Sub Assy 9374416127
7 Emblem Rear 9351355005
8 Propeller Fan Assy 9366378020
9 Motor, DC Brushless 9601882015
10 Condenser A Assy 9374433056
11 Valve Cover 9374174010
12 Strainer Assy 9372524015
13 Separate Wall 9374413133
15 Base Assy 9374166138
17 3-Way Valve Assy 9372205044
18 3-Way Valve Assy 9372205075
19 Check Joint Assy 9372802038
20 Compressor Assy 9372558126
21 Accumulator 9385005006
22 4-Way Valve 9900164010
23 Solenoid 9900165079
24 Pressure Switch 9900186012
25 Inlet Pipe (Cond) A Assy 9373461067
26 Accumulator Support Assy 313986353804
27 Outlet Pipe (Cond) A Assy 9374266104
28 Expansion Valve Assy 9370947144
29 Coil (Expansion Valve) 9900057039
31 PCB Case Assy 9375316013
33 Inverter Case 9375314019
35 ACTPM 9703457012
36 Thermistor 9704265012
37 Controller PCB Assy 9707121179
38 Power Supply PCB Assy 9707128062
39 Capacitor PCB Assy
9707257014
40 TR PCB Assy (IPM)
9707125085
41 Choke Coil 9900366018
42 Terminal
9900203023
45 Discharge Temp Thermitor 9704219114
46 Thermistor (Outdoor Temp) 9900378028
47 Compressor Temp Thermistor 9900156022
48 Heat Exchanger Thermistor 9900374013
9374417032
9374094066
9374330010
9374173013
9374415052
9374416127
9351355005
9366378020
9601882015
9374433056
9374174010
9372524015
9374413133
9374166138
9372205044
9372205075
9372802038
9372558126
9385005006
9900164010
9900165079
9900186012
9373461067
313986353804
9374266104
9370947144
9900057039
9375316013
9375314019
9703457012
9704265012
9707121162
9707128062
9707257014
9707125085
9900366018
9900203023
9704219114
9900378028
9900156022
9900374013
Part No.
Description
2006.08.21 22
