Fujitsu AOY30UNBWL User Manual

ADDITIONAL REFRIGERANT CHARGE (R410A)
Pipe Length 7.5 m (25 ft) 2,300 g (81.1 oz) 2,300 g (81.1 oz)
10.0 m (33 ft) 2,350 g (82.9 oz) 2,400 g (84.7 oz)
20.0 m (66 ft) 2,550 g (89.9 oz) 2,800 g (98.8 oz)
30.0 m (99 ft)
2,750 g (97.0 oz) 3,200 g (112.9 oz)
ADDITIONAL CHARGE
FULL CHARGE
AMOUNT
20 g / m (0.21 oz/ft) 40 g / m (0.43 oz/ft)
SPECIFICATIONS
TYPE
COOLING COOLING & HEATING
INDOOR UNIT ARY30FUAN ARY30UUAN
OUTDOOR UNIT AOY30FNBWL AOY30UNBWL
COOLING CAPACITY
(kW)
(kW)
8.40 8.40
HEATING CAPACITY
---- 9.50
POWER SOURCE
(V)
(Hz)
230
FREQUENCY
RUNNING
(A)
COOLING 14.0 14.0
CURRENT
HEATING ---- 12.4
INPUT WATTS
(kW)
COOLING 2.99 2.99
HEATING ---- 2.63
E.E.R.
(kW/kW)
COOLING 2.81 2.81
HEATING ---- 3.61
MOISTURE REMOVAL
( /hr)
3.0
AIR CIRCULATION
(m
3
/hr)
1,400
ELECTRICAL DATA
FAN MOTOR
COMPRESSOR
Hermetic type, 2 poles, Induced by condenser, Rotary
5JS330DAE01
(V) 230
DISCRIMINATION MFA-30PTT
INDOOR
HI-SPEED ( r.p.m. ) 990
UNIT
MED-SPEED ( r.p.m. ) 920
LO-SPEED ( r.p.m. ) 850
OUTDOOR
DISCRIMINATION MFB-30PTT
HI-SPEED ( r.p.m. ) 780
UNIT
LO-SPEED ( r.p.m. ) 400
WEIGHT
INDOOR UNIT
NET / GROSS
43 / 50
OUTDOOR UNIT
(kg)
NET / GROSS (kg)
68 / 74 69 / 75
50
DIMENSIONS
INDOOR UNIT
H x W x D
270 x 1,135 x 700
OUTDOOR UNIT
(mm)
H x W x D (mm) 830 x 900 x 330
FAN NOISE
High 50 dB 50 dB
Med 48 dB 48 dB
Low
45 dB 45 dB
OUTDOOR UNIT
INDOOR UNIT
- -
TYPE
DISCRIMINATION
POWER SOURCE
2005.04.27 1

Fujitsu AOY30UNBWL Specifications

General

Brand	Fujitsu
Model	AOY30UNBWL
Category	Air Conditioner
Language	English
