Ref Ord
No. UTF-Y54A1A UTF-Y90A4A Q'ty
108 BASE ---------------- 9362189002
108 BASE ASSY 9362719001 ----------------
199- BR SHEET 9363708011 9363708011
199 BR SHEET 9363708028 9363708028
910 CAPILLARY TUBE B ---------------- 9365965009
212/466 CLAMP 313714328805 313714328805
195 CLAMP 313361275805 313361275805
464-1 COVER 9362718004 ----------------
464 COVER ASSY ---------------- 9362190008
450 DISCHARGE GAS PIPE ---------------- 9362179003
450-1 DSCG GAS PP ASSY 9362222006 ----------------
186 EDGE COVER ---------------- 9361049024
964 FLARE NUT-A ---------------- 313996239804
964 FLARE NUT-A ---------------- 9357352022
150 HALF UNION-B 9357351018 9357351018
468 HOOK METAL 9362865005 9362865005
167-4 INS ( SEPARATE WALL ) A ---------------- 9362868068
167-5 INS ( SEPARATE WALL ) B ---------------- 9365901007
167-6 INS ( SEPARATE WALL ) C ---------------- 9365908006
167-7 INS ( SEPARATE WALL ) D ---------------- 9367098002
167 INSULATION A 9364188003 ----------------
167-1 INSULATION A ---------------- 9364190006
167-1 INSULATION B 9364189000 ----------------
167-2 INSULATION B ---------------- 9364191003
167-3 INSULATION C ---------------- 9364192000
167 INSULATION ( BASE ) 9362868075 9362868075
154 INSULATION ( PIPE ) A ---------------- 9364738000
98/155 INSULATION ( PIPE ) B ---------------- 9364739007
267 INSULATION ( PIPE ) C ---------------- 9364740003
267-3 INSULATION ( PIPE ) D ---------------- 9364741000
368 INSULATION ( PIPE ) E ---------------- 9364742007
154 INSULATION ( PIPE ) A 9364735009 ----------------
155 INSULATION ( PIPE ) B 9364736006 ----------------
267 INSULATION ( PIPE ) C 9364737003 ----------------
760 INSULATION ( PIPE ) F 9365850008 9365850008
760-1 INSULATION ( PIPE ) G 9365851005 ----------------
760-2 INSULATION ( PIPE ) H ---------------- 9365853009
568-1 JNT WIRE ( SLN VLV ) A 9365848005 9365848005
568-2 JNT WIRE ( SLN VLV ) A 9365849019 9365849019
564-5 LIQUID PIPE ASSY ---------------- 9362182003
MANUAL ( INSTALLATION ) ---------------- 9366247012
468 NUT-A M8 9356998009 9356998009
PACKING CASE-CARTON 9301094015 9301094015
674 PROJECTION BOLT 9356901023 9356901023
273 REAR PANEL ---------------- 9362191005
273 REAR PANEL 9362721004 ----------------
295-1 REDUCER A 9364430003 9364430003
295-4 REDUCER D ---------------- 9364433004
295-5 REDUCER F ---------------- 9364434001
295-6 REDUCER F ---------------- 9364435008
295-2 REDUCER I 9364438009 9364438009
295-3 REDUCER J 9364439006 9364439006
29 SEPARATE WALL ---------------- 9362192002
29 SEPARATE WALL 9362722001 ----------------
457-2 SOLENOID VALVE 9703889035 9703889035
457-3 SOLENOID VALVE 9703889042 9703889042
457-1 SOLENOID VALVE 9703889059 9703889059
157-4 SOLENOIDE 9703888113 9703888113
157-5 SOLENOIDE 9703888120 9703888120
157-6 SOLENOIDE 9703888137 9703888137
157-7 SOLENOIDE 9703888144 9703888144
468 SPECIAL NUT-A ( LARGE ) 313005446653 313005446653
169 SPECIAL NUT-B ( SMALL ) 313005446759 313005446759
272 STRAINER 9363119008 9363119008
909 STRAINER A 9365954003 9365954003
909-1 STRAINER A ---------------- 9363118001
910 STRAINER B 9365955000 9365955000
910-1 STRAINER B ASSY 9363121001 9363121001
327-1 SUC GAS PP A ASSY 9362224000 ----------------
327-2 SUC GAS PP B ASSY 9362226004 ----------------
327-3 SUC GAS PP C ASSY ---------------- 9362188005
327-4 SUCTION GAS PIPE A ---------------- 9362185004
326 3-WAY JOINT 9354901001 9354901001
Description
Parts No.
– 175 –
Models :
UTF-Y90A4A
UTF-Y54A1A
